- Riving knife maintains close blade proximity to reduce chance of kickback
- 80 of solid cast iron provides a massive work surface
- Poly V-Belt increases efficiency and reduces slipping and vibration
- Collection shroud around the blade and integrated hose improve dust collection
- Integrated arbor lock is accessed from table top for rapid blade change
- External tool storage for the fence and miter gauge
- 40-1/2 fence provides greater stability and better support when ripping
- Dado insert included
- Maximum rip left of the blade is 14
- Removal of blade guard, pawls and riving knife takes only seconds
| Height | 42.000 |
| Length | 86.000 |
| Gross Weight | 669.300 |
| Net Weight | 623.000 |
| Volume | 66.889 |
| Width | 32.000 |
| Ready For Web (US) | Yes |
| Prop 65 | Cancer and Reproductive Harm |
| Recommended Circuit Size (Amps.) | #N/A |
| Motor Voltage (V.) | 230 |
| Table Height from Floor (In.) | #N/A |
| Maximum Depth of Cut at 45 Degrees (In.) | 2-7/8 |
| Motor Power (HP) | 5 |
| Maximum Width of Dado (In.) | 13/16 |
| Distance Between Sliding Table and Blade (In.) | #N/A |
| Table Size (L x W) (In.) | 31-1/2 x 24 |
| Table in Front of Saw Blade at Maximum Depth of Cut (In.) | #N/A |
| Table Size with Extension (L x W) (In.) | 31-1/2 x 80 |
| Motor Amps | 20 |
| Motor Phase (PH) | 1 |
| Arbor Speed (RPM) | 4300 |
| Maximum Rip Left of Blade (In.) | 14 |
| Maximum Depth of Cut (In.) | 4 |
| Miter Gauge Type | T-Slot with Stops |
| Table Type | Cast Iron |
| Arbor Diameter (In.) | 1 |
| Dust Collection Minimum CFM Required (CFM) | 350 |
| Maximum Rip Right of Blade (In.) | 50 |
| Wiring Remarks | #N/A |
| Prewired Voltage (V.) | 230 |
| Maximum Diameter of Dado (In.) | 8 |
| Blade Diameter (In.) | 12 |
| Table T-Slot (In.) | #N/A |
| Table Size with Full Extensions (L x W) (In.) | #N/A |
| Style (Type) | SV_1375591258815 |
| Dust Port Outside Diameter (In.) | 4 |
| Motor Current (Amps.) | #N/A |
| Motor Phase | #N/A |
