- Oscillating feature reduces heat build-up on sanding belt to reduce loading and burning which increases belt life
- Quick release lever and tracking control dial are conveniently located for replacing and tracking belts
- Belt platen is made from precision-ground steel plate for strength and durability
- Graphite covered platen runs cooler increasing machine and belt life
- Cast iron table moves up or down to provide exact workpiece positioning
- 4 dust port hooks up to your dust collection system for efficient dust removal
- Adjustable outer drum support table enables contour sanding
- Tilting sanding head for sanding bevels, angles and flat surfaces
| Height | 20.000 |
| Length | 50.000 |
| Gross Weight | 275.000 |
| Net Weight | 258.000 |
| Volume | 15.336 |
| Width | 26.500 |
| Ready For Web (US) | Yes |
| Prop 65 | Cancer and Reproductive Harm |
| Motor Phase | 1 |
| End Table Tilt (Deg.) | |
| Prewired Voltage (V) | 115 |
| Drum Diameter (In.) | |
| End Table Size (In.) | |
| Oscillation Stroke (In.) | |
| Style (Type) | Floor |
| Belt Speed (SFPM) | |
| Electrical Controls | |
| Platen Size (In.) | |
| Recommended Circuit Size (Amps.) | |
| Main Table Tilt (Deg.) | 90 |
| Oscillations Per Minute | |
| Sanding Belt Size (L x W) (in) | 89 x 6 |
| Wiring Remarks | |
| Motor Current (Amps.) | |
| Motor Voltage (V) | 115 |
| Dust Collection Minimum CFM Required (CFM) | |
| Table Height from Floor (In.) | |
| Main Table Size (LxW) (In.) | 29-3/4 x 9-7/8 |
| Motor Power (HP) | 1-1/2 |
| Dust Port Outside Diameter (In.) | 4 |
| Motor Amps | 18/9 |
| Belt Speed (RPM) | 3,900 |
