FEED ROLLS & PRESSURE ROLLS
- Bottom Rolls – 7 pieces in Front Section & 5 pieces in Rear Section
- Top Front section is equipped with 7 pressure rollers & 3 air cylinders controlled by sensor
- Top Rear section is equipped with 5 pressure rollers & 1 air cylinder controlled by sensor
| Motor | 20 HP + ½ HP + 5 kW (Servo ) + 2 HP Blower |
| Max. Working Thickness | 200 mm |
| Min. Working Thickness | 60 mm |
| Max. Working Width | 150 mm |
| Min. Working Length | 300 mm |
| Feed Speed | 0.1~2.0 m/min |
| Main Shaft Speed | 480 RPM, stroke distance 210 mm |
| Saw blade Size | 500 x 40 x 0.8 mm, Kerf: 1.2 mm, Pitch: 15, Stellite |
| Max Saw blades | 24 Pieces |
| Finished Tolerance Value | ± 0.1 mm |
| Min Precision Thickness | 2.0 mm |
| Dust Pipe | 5″x 4 Pieces |
| Machine Dimensions | L3800 x W1000 x H1900 mm |
